Semikron Danfoss Standard Photo SEMiX 5p

27923060VM04

SEMiX405MLI10S7SC-M04

SEMiX 5p

Product specifications

Characteristic
Value
Chip technologySiC Diode + IGBT S7
Country of originItaly
Current (A)400 A
Dimensions (LxWxH)130x70x17
Features950V Generation 7 freewheeling diodes (EC7)Reliable mechanical design with injection moulded terminalsNTC temperature sensor insideSilicon Carbide (SiC) clamping diodesSolderless assembling with PressFIT signal pins, screw power terminals950V Generation 7 IGBTs (S7, L7)UL recognized file no. E63532
HousingSEMiX 5p
Product StatusIn Production
Product lineSEMiX
TechnologyHybrid SiC
Topology3-Level
TypeSEMiX 5p
Typical applicationsSolar
VariantHALA P8
Voltage (V)950 V

General specifications

Characteristic
Value
Proposition 65Cancer and Reproductive Harm
