Product specifications
Characteristic | Value |
|---|---|
| Channels | 2 |
| Chip Technology | IGBT 3 (Trench) |
| Current (A) | 1000 A |
| Dimensions (LLxBBxHH) mm | 200x215x156 |
| Features | SKiiP technology insideTrench IGBTsCAL diode technologyIntegrated current sensorIntegrated temperature sensorIntegrated heat sinkUL recognized File no. E63532 |
| Housing | SKiiP 3 |
| Part Number | 20452180 |
| Product Group | SKiiP |
| Product Line | SKiiP 3 |
| Product Status | In production |
| Product Type | SKiiP 1013 GB172-2DL V3 |
| Surge Current (A) | 1072 A |
| Switches | Half Bridge |
| Technology | IGBT |
| Typical Applications | Renewable energiesTractionElevatorsIndustrial drives |
| Voltage (V) | 1700 V |
